PFA PINK FUSED ALUMINA F14
PFA Pink Fused Alumina F14 Chemical Composition
PFA Pink Fused Alumina F14 | Al2O3(%) | Cr2O3(%) | Na2O(%) | Fe2O3(%) |
Low Chromium | ≥98.5 | 0.2-0.45 | ≤0.3 | 0.01-0.05 |
Medium Chromium | ≥98.2 | 0.45-1.00 | ≤0.3 | 0.01-0.05 |
High Chromium | ≥97.5 | 1.00-2.00 | ≤0.35 | 0.01-0.05 |
PFA Pink Fused Alumina F14 PSD
MESH | DIAMETER/UM | % |
+8 | +2360UM | 0 |
+12 | +1700UM | ≤20% |
+14 | +1400UM | ≥45% |
+14+16 | +1400UM+1180UM | ≥70% |
-16 | -1000UM | ≤3% |
PFA Pink Fused Alumina Main Applications
1.PFA Pink Fused Alumina is used for precision grinding of measuring tools, lathe main shafts, instruments and apparatus parts, threading work pieces and many other applications in grinding like flute grinding, tooth grinding, dry grinding of blade segments, tool and internal grinding and mounted point.
2.PFA Pink Fused Alumina is the best suitable for high alloy steel applications, ideal for tool sharpening such as high speed steel cutters, reamers, chisels, end mill and sharpening band saw blades.
3.PFA Pink Fused Alumina is also recommended for knife-sharpening applications, working non-ferrous metals and the alloys.
4.PFA Pink Fused Alumina has good performance for vitrified bonded abrasives , vitrified grinding wheels, coated abrasives and blasting abrasives.
5.PFA Pink Fused Alumina can also be used for softer materials, such as wood, Synth-etics, etc.
Packaging of PFA Pink Fused Alumina
Production lines of PFA Pink Fused Alumina
|
Production Sizes of PFA Pink Fused Alumina
Fepa | F012 F014 F016 F020 F022 F024 F030 F036 F040 F046 F054 F060 F070 F080 F090 F100 F120 F150 F180 F220 |
JIS | #12 #14 #16 #20 #24 #30 #36 #40 #46 #54 #60 #70 #80 #90 #100 #120 #150 #180 #220 |
